A type double beam gantry cranes with hoist and hook outdoor gantry crane machine

Products information

H model single beam mobile electric hoist european single girder gantry crane

A type double beam gantry cranes
Lifting capacity t 50/10 75/20
Span m 18 22 26 30 35 18 22 26 30 35
Lifting Height Main m 10 12 10 12
Aux 10.9 12.9 11 13
Working system A5(intermediate)
Speed Hoisting Main m/min 5.9 47
Aux 13.2 9.2
crab travelling 38.5 38.4
trolley travelling 40.1 44 44 38.3
lnstalled Power 141.5 157.5 201 201
Max.wheel Load KN 370 370 380 420 430 380 390 410 310 340
Steel track Recommended QU80 QU80
Power source 3-phase A.C. 50Hz 380v
Main Dimensions K MM 2500 4400
W 8000 9000 9000 1000
We 3580 3300
B 11962 13270 13270 15376
BL 1800 2000 2000 2500
A 700 700 660
H1 1000 12000 11000 13000
H2 1000 12000 10000 12000
H3 948 1154
H4 15880 16080 18080 18742 19242
C 1195 1295
L1 8000 10500 8000 10500
L2 8000 10500 8000 10500
C1 5000 7500 5000 7500
C2 5000 7500 5000 7500
D 1316 1366 1441
E 900 1200 1200 1300

A type double beam gantry cranes with hoist and hook outdoor gantry crane machine

A type double beam gantry cranes with hoist and hook outdoor gantry crane machineA type double beam gantry cranes with hoist and hook outdoor gantry crane machineA type double beam gantry cranes with hoist and hook outdoor gantry crane machine

The company

A type double beam gantry cranes with hoist and hook outdoor gantry crane machineA type double beam gantry cranes with hoist and hook outdoor gantry crane machineA type double beam gantry cranes with hoist and hook outdoor gantry crane machineA type double beam gantry cranes with hoist and hook outdoor gantry crane machine

Q: What is our factory product range?

A: Mainly engaged in general bridge crane, general gantry crane, trackless gantry, trackless small gantry, trackless turning gantry, manual simple gantry, cantilever crane, manual single beam, electric hoist, electric hoist accessories, crane accessories, ring chain electric hoist, guide rail hydraulic elevator, electric flat car, European electric hoist, KBK soft crane, hydraulic lifting platform Lifting equipment, small lifting machinery, lifting tools and other lifting accessories. The company specializes in the installation, transformation, maintenance of a variety of single, double beam crane, electric hoist and other lifting equipment, and equipped with various models of lifting accessories. Undertake crane design, manufacturing, installation, repair, maintenance, demolition, transformation, relocation, on-site production, annual review, quality inspection etc.



Q: What information should I provide if I want to order the products?

A:
1) Product information: Quantity, specification (capacity, lifting height, voltage, size, material, color and packing requirements, how about working environment power source or other specials)
2) Delivery time required.
3) Shipping information: Company name, address, phone number, destination seaport/air port.
4) Forwarder’s contact details if there is any in China.



Q: How about your payment terms?
A: 30% deposit, with the balance before delivery, we accept T/T and L/C at sight.



Q: Can I use our own logo?
A: Yes, we can produce by using your own logo if you need.



Q: What’s the sample policy?

A: We can send you 1pcs of sample for your test, but you need to pay for the sample fee and delivery expenses, as it’s our company’s rule. Pls contact us for the sample details.



Q: How about sample & MOQ policy?

A: Welcome sample order. MOQ can be 1 set.



Q: What is your lead time for your goods?

A: Normally 20 days after confirmed order, 15 days could be available for some items in sufficient stock and standard requirements, and 40 days during new year and hot season ( Jan to March)
